Description

USB 3.2 Gen 2x2 cable with up to 20 Gbit/s speed mode that uses a more efficient data encoding and will deliver more than twice the effective data through-put performance of existing, fully backward compatible USB connectors and cables.

• High quality USB 3.1 / USB 3.2 Gen 2x2 cable with improved shielding
• With the reversible Type C connectors at both ends
• Gold-plated contacts for low wear at high plugging cycles
• Suitable for data transfer rates of up to 20 Gbit/s
• Supports USB Power Delivery to 20V / 5A

ROLINE GREEN products are marked only with a paper tag and build with halogen-free TPE material, without plastic bags and without plastic cable straps for use in eco-friendly environments.

Note: According to the current specifications of USB.org we have adapted the technical data of our USB 3 products. The new designation for the already known USB specifications has been changed to USB 3.2 Gen 1 (formerly USB 3.0 / USB 3.1 Gen 1) and USB 3.2 Gen 2 (formerly USB 3.1 / USB 3.1 Gen 2).

Specifications

Manufacturer	ROLINE GREEN
Product group	Cable
Product type	USB 3.2 Cable
Colour	black
Length	1 m
Scope of delivery	Cable without plastic bag, only marked with a paper label
Transfer quality	USB 3.2 Gen 2x2 SuperSpeed 20 Gbit/s
Connection ports	USB Type C (USB-C) Male / USB Type C (USB-C) Male
Side 1 Connector Type	USB Type C (USB-C)
Side 1 Connector Gender	Male
Side 2 Connector Type	USB Type C (USB-C)
Side 2 Connector Gender	Male
Maximum data transfer rate	20 Gbit/s
Area of application	External
Supported charging technology	USB-PD - USB Power Delivery
Power (max.)	100 W
Cable shielding	Screened
Hand locking screws	no
Material (external cable mantle)	TPE
Cable LSOH	halogen-free
Weight	35 g
Height of packaging (single piece)	10 mm
Width of packaging (single piece)	50 mm
Depth of packaging (single piece)	50 mm
Package weight (single piece)	0.02 kg

Downloads

Product data sheet - English (50.4 KB)

Download

Manufacturer data sheet - English (105.7 KB)

Download

Help our environment and avoid unnecessary plastic waste



For our ROLINE GREEN series, we have selected a number of well-known ROLINE quality products for which we do not use plastic bags and plastic cable ties.

Instead, the products are only marked with a paper label.

The cables themselves are made of halogen-free TPE material to avoid the classic sheath material PVC.
